MIT physicists have captured the first images of individual atoms freely interacting in space. The pictures reveal correlations among the “free-range” particles that until now were predicted but never directly observed. Their findings, appearing today in the journal Physical Review Letters, will help scientists visualize never-before-seen quantum phenomena in real space.
The images were taken using a technique developed by the team that first allows a cloud of atoms to move and interact freely. The researchers then turn on a lattice of light that briefly freezes the atoms in their tracks, and apply finely tuned lasers to quickly illuminate the suspended atoms, creating a picture of their positions before the atoms naturally dissipate.
The physicists applied the technique to visualize clouds of different types of atoms, and snapped a number of imaging firsts. The researchers directly observed atoms known as “bosons,” which bunched up in a quantum phenomenon to form a wave. They also captured atoms known as “fermions” in the act of pairing up in free space — a key mechanism that enables superconductivity.
“We are able to see single atoms in these interesting clouds of atoms and what they are doing in relation to each other, which is beautiful,” says Martin Zwierlein, the Thomas A. Frank Professor of Physics at MIT.
In the same journal issue, two other groups report using similar imaging techniques, including a team led by Nobel laureate Wolfgang Ketterle, the John D. MacArthur Professor of Physics at MIT. Ketterle’s group visualized enhanced pair correlations among bosons, while the other group, from École Normale Supérieure in Paris, led by Tarik Yefsah, imaged a cloud of noninteracting fermions.
The study by Zwierlein and his colleagues is co-authored by MIT graduate students Ruixiao Yao, Sungjae Chi, and Mingxuan Wang, and MIT assistant professor of physics Richard Fletcher.
Inside the cloud
A single atom is about one-tenth of a nanometer in diameter, which is one-millionth of the thickness of a strand of human hair. Unlike hair, atoms behave and interact according to the rules of quantum mechanics; it is their quantum nature that makes atoms difficult to understand. For example, we cannot simultaneously know precisely where an atom is and how fast it is moving.
Scientists can apply various methods to image individual atoms, including absorption imaging, where laser light shines onto the atom cloud and casts its shadow onto a camera screen.
“These techniques allow you to see the overall shape and structure of a cloud of atoms, but not the individual atoms themselves,” Zwierlein notes. “It’s like seeing a cloud in the sky, but not the individual water molecules that make up the cloud.”
He and his colleagues took a very different approach in order to directly image atoms interacting in free space. Their technique, called “atom-resolved microscopy,” involves first corralling a cloud of atoms in a loose trap formed by a laser beam. This trap contains the atoms in one place where they can freely interact. The researchers then flash on a lattice of light, which freezes the atoms in their positions. Then, a second laser illuminates the suspended atoms, whose fluorescence reveals their individual positions.
“The hardest part was to gather the light from the atoms without boiling them out of the optical lattice,” Zwierlein says. “You can imagine if you took a flamethrower to these atoms, they would not like that. So, we’ve learned some tricks through the years on how to do this. And it’s the first time we do it in-situ, where we can suddenly freeze the motion of the atoms when they’re strongly interacting, and see them, one after the other. That’s what makes this technique more powerful than what was done before.”
Bunches and pairs
The team applied the imaging technique to directly observe interactions among both bosons and fermions. Photons are an example of a boson, while electrons are a type of fermion. Atoms can be bosons or fermions, depending on their total spin, which is determined by whether the total number of their protons, neutrons, and electrons is even or odd. In general, bosons attract, whereas fermions repel.
Zwierlein and his colleagues first imaged a cloud of bosons made up of sodium atoms. At low temperatures, a cloud of bosons forms what’s known as a Bose-Einstein condensate — a state of matter where all bosons share one and the same quantum state. MIT’s Ketterle was one of the first to produce a Bose-Einstein condensate, of sodium atoms, for which he shared the 2001 Nobel Prize in Physics.
Zwierlein’s group now is able to image the individual sodium atoms within the cloud, to observe their quantum interactions. It has long been predicted that bosons should “bunch” together, having an increased probability to be near each other. This bunching is a direct consequence of their ability to share one and the same quantum mechanical wave. This wave-like character was first predicted by physicist Louis de Broglie. It is the “de Broglie wave” hypothesis that in part sparked the beginning of modern quantum mechanics.
“We understand so much more about the world from this wave-like nature,” Zwierlein says. “But it’s really tough to observe these quantum, wave-like effects. However, in our new microscope, we can visualize this wave directly.”
In their imaging experiments, the MIT team were able to see, for the first time in situ, bosons bunch together as they shared one quantum, correlated de Broglie wave. The team also imaged a cloud of two types of lithium atoms. Each type of atom is a fermion, that naturally repels its own kind, but that can strongly interact with other particular fermion types. As they imaged the cloud, the researchers observed that indeed, the opposite fermion types did interact, and formed fermion pairs — a coupling that they could directly see for the first time.
“This kind of pairing is the basis of a mathematical construction people came up with to explain experiments. But when you see pictures like these, it’s showing in a photograph, an object that was discovered in the mathematical world,” says study co-author Richard Fletcher. “So it’s a very nice reminder that physics is about physical things. It’s real.”
Going forward, the team will apply their imaging technique to visualize more exotic and less understood phenomena, such as “quantum Hall physics” — situations when interacting electrons display novel correlated behaviors in the presence of a magnetic field.
“That’s where theory gets really hairy — where people start drawing pictures instead of being able to write down a full-fledged theory because they can’t fully solve it,” Zwierlein says. “Now we can verify whether these cartoons of quantum Hall states are actually real. Because they are pretty bizarre states.”
This work was supported, in part, by National Science Foundation through the MIT-Harvard Center for Ultracold Atoms, as well as by the Air Force Office of Scientific Research, the Army Research Office, the Department of Energy, the Defense Advanced Projects Research Agency, a Vannevar Bush Faculty Fellowship, and the David and Lucile Packard Foundation.
